Dust Level Sensor
Created: October 23, 2005
Updated: January 12, 2018
Challenge
I make a lot of wood dust, love your cyclone that works incredibly well
compared to my first two cyclones, but keep having problems with filling
the filters full of dust because I forget to empty the dust bin. What do
you recommend to help me know when to empty the bin? What do you use? -
Jeff
Jeff, this gets asked often and is an important question. No matter how
efficiently a cyclone separates off the dust, as soon as the dust bin gets
full everything goes right through the cyclone into the filters. Because
most small shop owners use far less than the monster horsepower blowers
used in large commercial woodworking facilities, dirty filters quickly
kill the airflow from our less powerful blowers that we need for good fine
dust collection. Cleaning our expensive filters quickly wears them out
opening the pores so they freely pass the finest unhealthiest dust right
through. I tend to get overly involved in what I am doing and regularly
forget to empty the dust bin, especially when making lots of dust. As a
result, cleaning my filters continues to be an ongoing problem. I
installed a sealed clear polycarbonate window in my dust bin so I can see
when it is getting full. The theory was good but it works poorly. The
chips flying around inside the bin rubbing on that plastic creates a
static charge. That static charge attracts a thick coat of fine dust that
covers the window. Wiping that plastic with clothes drier fabric softener
sheets helps some, but not enough. The same goes for my later efforts to
add electronic sensors to my bin. My weight triggered approach and also my
photo cell approach failed badly. The weight triggered approach assumed
the dust created is a fairly constant weight. It is not and the weight
needed to tell me when my bin is full of light planer shavings is about
one tenth that for a full bin of MDF dust. Likewise, the photocell
technique that others also tried constantly gives off bad readings due to
the sensor and light getting dirty or covered with a chip. In short, a
full dust bin has remained an ongoing problem. The no longer available
clear plastic cyclones solved this problem because they let us see when
the dust is not dropping, unfortunately, we still have to look. That’s
why I am sharing a better solution shared by Hajime Sugisawa. "Sugi" is a
bright electronics fellow who wanted to give a little back after building
my cyclone design. His English language skills are a little challenged,
but infinitely better than my Japanese, so I am sharing his design.
Alternative 1: Since I published this design, others have shared a fix
that actually makes a simple photocell solution viable. Instead of putting
the light and sensor inside the dust bin, putting windows at the bottom of
the pipe just before it connects to the top of the dust bin allows putting
a small Christmas tree light on one side and standard 120V photocell used
to control outdoor lights on the other. When the light is blocked that
cell turns on an AC power source. You can have that power either ring a
bell or have it activate a relay which cuts power to your motor switch.
This works well, is cheap, requires no special parts, and turns off the
cyclone blower motor when the bin fills just into the hose. There is
enough scouring that the windows stay clean.
Alternative 2: I continue to play with many different things including
robotics. If you want another more elegant inexpensive alternative
consider using one of the inexpensive robotic microprocessor boards
coupled to this Sharp distance sensor. Make sure you order the pigtail
cable with it as the leads are difficult to solder onto.
Request
I am sharing this information as a service only. Please do not email me
with electronic questions. I burned out on digital design as a career back
in the early seventies after building my first computer from scratch and
teaching college digital electronic design classes for years. This is one
of the fastest changing areas ever. My range of activities and limited
time left me struggling to keep up and eventually saying enough. I have no
interest in getting back into digital electronics and again becoming
current. Although I am happy to accept advice, safety, and improvement
suggestions, I really do not want to field electronic questions because my
interest is too little and knowledge too dated. Likewise, I long ago
learned that recommending part suppliers is a never ending maintenance
chore, so I am sharing Sugi’s links and a link to All Electronics that I
have long used as a source for my own parts. I am not going to maintain
these links nor going to take responsibility for looking at or blessing
other alternatives. A number of people have build these sensors
successfully, but a few have provided some feedback that this design can
be improved with a few changes. I've included some feedback from Doug who
worked through some problems when building this unit. Finally, any time
you work with electricity and fine dust, there are potential hazards.
Please read my below disclaimer and either know what you are doing or get
competent help to ensure what you build is safe.
Summary
This simple sensor costs about $20 to build and works well. It shows a
light when working and when the dust bin gets full that light goes out and
a buzzer sounds. This detector is built from a solar motor, 12 volt DC
transformer, and a few readily available electronic parts. The motor is
mounted outside the dust bin with a small fan sitting inside. The fan
stops turning when the dust level gets near the top of the bin and blocks
fan rotation. Sugi’s circuit senses when the fan stops turning and turns
off the bright light emitting diode (LED) light and turns on the buzzer.
Because the current is so small, this approach will not harm the motor
when it is blocked nor does it pose a fire danger. This circuit buzzes on
startup for a few seconds while the solar motor fan comes up to speed
letting us know the circuit works. A switch to the buzzer can easily be
added or the buzzer left out of the circuit if noise is a problem. That
still leaves the LED turning off to show when the bin is full, but would
not work for me as I need a strong buzzer to get my attention.
Principle
The solar motor runs about 300-1000 RPM with 15-100mA current while
most popular DC toy motors run at 5000 to 10000 RPM with 100-500mA. Unlike
toy motors, the slower rotation and reduced current for the solar motor
allows our dust to easily stop the impeller.
In this circuit, the solar motor is connected in serial to resistor R1
and current is limited about 20mA at a constant rotation. When the
terminal voltage is about 1 volt, then Q1 is activated turning the LED
light on and Q2 off, so the buzzer does not sound.
But when the Impeller (motor) rotation is interrupted, the voltage
falls down almost 0 volts. Q1 goes off turning off the LED and activating
Q2 which sounds the buzzer letting us know it is time to empty the dust
bin.
When starting the solar motor needs extra current which is why C1 is
included in the circuit.
Fig.1A Parts List
This is the original circuit, but Sugi had reports that this shematic
doesn't work correctly if the motor voltage is higher than Q1 threshhold
(about 0.6V) at the time the force is stopped. So, he made some
modifications to correct this that also makes adustment easier. (See
Below)
Figure.1A
Part Discription EQV US Part Vendor
Solar Motor H-151Solartek #700-60062-00
http://store.sundancesolar.com
Impeller Plastic 60mm dia. Note1
Q1 2SC1815 2SC1775A www.allelectronics.com
Q2 2SC1815 2SC1775A same above
D1 1S1558 IN4002 same above
LED Unknown spec. LED-120 same above
Buzzer 12V DC SBZ-100 same above
C1 470uF 25V 470uF 25V same above
R1 600 ohm Note2
R2 10Kohm 1/4W 10Kohm 1/4W same above Note3
R3 1Kohm 1/4W 1Kohm 1/4W same above Note3
R4 10Kohm 1/4W 10Kohm 1/4W same above Note3
note1 If you don't find simular one,You can make it yourself
note2 Get this value by pararell connection of multiple resistors
note3 Typically sold 10 pieces minimum
Fig2B Parts List
This circuit adds LM393 which provides a couple of voltage comparaters
that detect a slight volatage difference. VR1 is the aduster of the
reference voltage.
Figure.2B
Part Discription EQV US Part Vendor
Solar Motor H-151Solartek #700-60062-00
http://store.sundancesolar.com
Impeller Plastic 60mm dia. Note1
U1 LM393 LM393 www.allelectronics.com
Q1 2SC1815 2SC1775A same as above
D1 1S1558 IN4002 same as above
LED1 Unknown spec. LED-2 same as above
LED2 Unknown spec. LED-1 same as above
Buzzer 12V DC SBZ-100 same as above
C1 470uF 25V 470uF 25V same as above
R1 600 ohm Note2
R2 10Kohm 1/4W 10Kohm 1/4W same as above Note3
R3 10Kohm 1/4W 10Kohm 1/4W same as above Note3
R4 10Kohm 1/4W 10Kohm 1/4W same as above Note3
R5 1Kohm 1/4W 1Kohm 1/4W same as above Note3
R6 1Kohm 1/4W 1Kohm 1/4W same as above Note3
VR1 2Kohm trimpot 2Kohm trimPot same as above Note4
note1 If you don't find simular one,You can make it yourself
note2 Get this value by pararell connection of multiple resistors
note3 Typically sold 10 pieces minimum()
note4 You can use both linear pot and trimmer pot(potention meter)
LPT-2.5K looks available.
Construction
Make some holes on a piece of aluminum angle to support the solar motor
and holding screw .I drilled through to hold an 8mm hex bolt and secured
the motor cable as pictured. Then unit is secured with this 8mm bolt and
nuts on either the top or side of dust can.
�@
This simple circuit easily was built on a lag terminal strip by
soldering without need for a printed circuit board. R1 is an assembly of
multiple resistors. See Fig.2. Resistors here are sold in 10 piece minimum
lots, so this made good use of having to buy so many.
Testing
After finishing construction, check all connections then connect the
12V DC adaptor. Buzzer sounds for a few seconds as the motor starts and
gradually comes up to full rotation speed. When at full speed the buzzer
should stop and the LED turns on.
Try stopping the impeller with your finger. If it blows too hard or
seems to move too fast, remove one 10K ohm resistor from R1 assembly. If
the motor rotational speed is not constant, add one more 10K ohm resistor
to R1 assembly. When the rotation stops the LED should turn off and the
buzzer sounds.
If the motor does not start again when you remove your finger,
disconnect and then reconnect the DC adaptor.
I keep this sensor running while I'm in my shop.
IMPORTANT Notes!
I made this circuit with parts available in Japan, you may have to
use other parts and it might take a little adjustment to work with a
different parts configuration. This is especially true if you use a
different fan because the detection sensitivity depends on the radius and
the shape of fan impeller (propeller).
If the impeller rotation sucks up dust, reverse the motor
connection so that impeller blows the other direction.
If you don't like buzzer noise, either put a switch in front of the
buzzer or remove R4, Q2 and buzzer. You then will only have the LED for
your indicator. (Bill’s note: You also could replace the buzzer with
some bright automotive flashing LEDs.)
To keep the impeller from being damaged by larger debris, you
should surround it with a wire guard.
Making Your Own Impeller - I made four small blades with aluminum sheet
(0.3mm thick, 20*30 mm wide) and mounted them on a small plastic rod that
was about 30 mm in diameter and 10 mm thick. (Bill’s note: You also
could make two longer blades, cut opposing slots, and slide them together
to keep from having to worry about the blades flying loose from their
mounting.)
I then made a 2.0 mm diameter through hole at the exact center for a
tight fit on the motor shaft followed by cutting four slits with an XACTO
saw (the blade thickness 0.27 mm) to hold the impeller blades.
Insert blades into slits. If they feel loose, use adhesive (for metal
and plastic).
I don't know this shape is best or not, but after adjusting a little
because it is heavier and draws a little more current, it works just fine.
Now that should allow you to build a pretty incredible dust bin sensor
for under $20.
Feedback
I just got done building the dust bin sensor. I discovered that the
schematic is incorrect. If you wire it as it is on your site, it will work
just the opposite as one would want i.e. when the motor is running, the
red light is lit and the buzzer sounds and when the motor is stalled, the
buzzer is silenced. I checked with a ham friend of mine and we put our
heads together and found that if you switch wiring to pins 2 and 3 of the
IC, that it works correctly. I also found that with the circuit as wired,
that the buzzer will give a high pitched noise when the motor is running,
I found that if I connected three diodes in series on the 12 volt side of
the buzzer, that the soft ringing could be eliminated. It reduces the
voltage to the buzzer enough to get rid of that resting whine. It likely
also reduces the voltage to the buzzer when it is summoned to work (when
the motor is stalled) and so also reduces the total volume of the buzzer
when it is supposed to alarm. I haven't hooked it up to the cyclone dust
bin yet, so I don't know if it will be too quiet to hear (however
according to all the complaints from my wife while I was testing it, it
should be OK. HaHa)
I also discovered that the supply voltage is quite critical. When I
used a "12 volt" "wall wart" supply (which actually produces 16 volts) it
didn't work (couldn't quiet it down).
I ended up using a "9 volt" supply (which actually produced 12 volts
and it worked just fine.
Just thought I would provide you with what I experienced.
Doug
I worked with Sugi and did find one problem, but now all the above
diagrams are fixed and work properly.
bill
Another Alternative
Jon Mackey is a fellow woodworker who like me enjoys tinkering with
electronics. He needed help knowing when his dust collection bin was full.
He checked into the photo based sensors and decided they just did not make
sense as there was too much chance of either the light or photocell
getting blocked and needing constant cleaning. He also looked at weight
and pressure sensors and realized wood dust weight is too inconsistent
depending on the type of wood and machining process. He researched how the
large professional firms sense a bin full condition and realized he could
build something similar that was both simple and affordable. He used an
Arduino processor, small motor and tiny circuit board with a simple
program as the smarts behind his sensor. If you would like to learn more
take a look at what he shared at his Dust Collector Bin Full Sensor site.
Additionally, Jon came up with a sensor and alarm to let him loudly know
when the bin was full at Bin Sensor Alarm site.
Diclaimer
